Wood Boiler Stove
AQUAFLAM 12
AQUAFLAM wood boiler stoves from HS Flamingo have many above-standard features. The primary benefit of these innovative features is that they simplify the operation of the stove. Only the finest materials are used in their production. Dual air wash of glass using preheated air. Four colour options for each model
secondary combustion
Ensures a clean glass and perfect combustion of gases thanks to a special inlet for secondary and tertiary air
firebrick-free technology
due to the absence of a firebrick lining, there is a larger surface area for increased water heating efficiency
safety cooling loop
A safety feature against overheating
Eko-Air-In - External air inlet
This innovative feature delivers high efficiency, up to a 40% reduction in fuel consumption
convection wood stove
even better heat delivery to a room
- Secondary combustion ensures a clean glass and perfect combustion
- Firebrick-free technology with increased water heating efficiency
- A Safety Cooling Loop against overheating
- External air inlet - up to a 40% reduction in fuel consumption
- Convection wood stove for even better heat delivery to a room
To ensure the safety of our customers, we have equipped these boiler stoves with a cooling loop. You can select from three types of regulation (manual, basic and automated).
An outside air inlet, secondary combustion and dual window air wash are features found on all of our stoves. AQUAFLAME boiler stoves meet the strictest European standards – BImSchV – Stufe 2, DINplus, Flamme Verte.
AQUAFLAM STOVES IN THE INTERIOR
COLOUR OPTIONS
Timeless look in four traditional colors
Secondary combustion – ensures a clean glass and perfect combustion of gases thanks to a special inlet for secondary and tertiary air / Dual air wash using preheated air / Firebrick-free technology – due to the absence of a firebrick lining, there is a larger surface area for increased water heating efficiency / Cooling Loop – a safety feature against overheating / External air inlet – Eko-Air-In System damper for regulating the chimney draught / Hot and cold water outlets on both sides / Three types of combustion regulation – manual, basic electronic and automated
CROSS SECTION OF THE COMBUSTION CHAMBER
TECHNICAL PARAMETERS
Aquaflam 12 | 12 kW |
|---|---|
Nominal power [kW] | 12 |
Nominal power into water [kW] | 10 |
Nominal power range [kW] | 8 – 16 |
Power into water range [kW] | 8 – 12 |
Stove efficiency [%] | 79,1 |
Smoke flue diameter [mm] | 160 |
Weight [kg] | 175 |
Log lenght [cm] | 35 |
Heating value [m3/h] | 160–320 |
CO emissions at 13% O2 [%] | 0,1 |
Average flue gas temperature [°C] | 247 |
Volume of heat exchanger [l] | 27 |
Maximum operating pressure [bar] | 2,5 |
We meet the standards | EN 13240, BlmSchV, Stufe 2, Ekodesign |
Warranty | 5 years |
Czech Product - Gold medal
Our Czech products are sold all over the world. They are exclusively produced by the Czech HS Flamingo team.
COMBUSTION CONTROL
Combustion Control - Manual
- operates without electricity
- controlled using a rod
- for those who prefer the classic style
- pull towards you to open the air inlet
Combustion Control - Basic
- simple to control directly on the insert
- can be connected to the mains with an external AC 230V/DC6V power supply (Product code: HSF17-196), eliminating the need to use and then replace 4 AA-LR6 batteries
- safety sensor that closes the damper in the event of overheating
- powered by long-life batteries
- overheating warning sound
Combustion Control - Automated
- simple user interface
- graphical display of sensors, pumps and temperatures
- easy installation and connection
- control of other heat sources
- control up to three pumps
- summer / winter heating modes
